Electric Forklift Truck

Your Professional Electric Forklift Truck Manufacturer & Supplier

Shandong Honor Crane Lifting Equipment Co., Ltd, established in 2014, is a specialized manufacturer dedicated to the R&D, production, and global sales of lifting equipment. Boasting a modern manufacturing facility spanning over 3,000 square meters, we possess an annual production capacity exceeding 1,000 sets of lifting equipment. Our product range includes:Hydraulic Scissor Lifts, Mobile Scissor Lift Platforms, Self-Propelled Scissor Lifts, Electric Forklift Truck, Dock Levelers, Customized Lifting Platforms.

2 Ton Electric Forklift

Add to Inquiry
2 Ton Electric Lithium Battery Forklift

Add to Inquiry
3 Ton Electric Forklift

Add to Inquiry
2 Ton Battery Operated Forklift

Add to Inquiry
5000 Lb Electric Forklift

Add to Inquiry
3 Wheel Electric Forklift

Add to Inquiry
Electric Counterbalance Forklift

Add to Inquiry

Why Choose Us

Advanced Equipment

We are equipped with CNC cutting machines, automated welding systems, hydraulic testing systems, painting production lines, and load testing equipment, thereby ensuring precision in our manufacturing processes and stability in product quality.

Quality Control

From raw material selection, structural fabrication, and hydraulic assembly to final inspection and testing, every stage is subject to rigorous management and control to ensure product safety, durability, and stable long-term performance.

Global Market Experience

Our products are exported to numerous regions—including Europe, Southeast Asia, the Middle East, South America, and Africa—allowing us to accumulate extensive experience in cross-regional technical adaptation, localized service provision, and regulatory compliance.

Specification

Product Name	5000 Lb Electric Forklift
Load Capacity (kg)	2500kg
Max Lifting Height	3000mm
Lift Speed (unload/full load)	480mm/s
Mast Lowered Height	2095mm
Self Weight	3900-4600kg
Battery(V/AH)	80V/250/350AH

Advantages of Electric Forklift Truck

01/

Environmentally-conscious
Electric-powered forklifts dramatically reduce your carbon footprint. In fact, they produce zero emissions which significantly minimises your environmental impact. This is a highly important factor to consider when you think about the current condition of the planet and focus on operating in a more sustainable way.

02/

Reduced noise pollution
Electric vehicles emit less noise than traditional internal combustion engines, making your general operations much quieter. A quieter environment allows operators to communicate with each other with greater ease and also reduces the risk of injury.

03/

Versatile
Electric-powered forklifts can be used both indoors and outdoors. The zero-emission advantage of electric trucks means that they emit no fumes, making them a perfect addition to warehouses and factories alike. They're also highly manoeuvrable – their small chassis enables a compact turning radius and makes the navigation of tight spaces like warehouse aisles seamless.

04/

Ergonomic design
Health, safety, and comfort. These are three factors that are necessary for operators to feel happy and confident at work. Compared to alternative trucks, electric forklift trucks offer operators a higher quality driving experience which works to reduce downtime, optimises efficiency, and improves the happiness of your workforce.

05/

Less maintenance
With fewer mechanical components, electric trucks require less maintenance, are easier and cheaper to maintain. They don't require regular fluid refills – like coolants and engine oil and are less likely to break down than diesel or gasoline-powered vehicles.

06/

Reduced TCO
Electric material handling equipment is more cost-effective than its gas or diesel-powered counterpart. The upfront cost must be noted, but the long-term cost savings garnered are significant and cannot be overlooked. Not only that, electric forklift trucks have a much longer lifespan.

Key Components of Electric Forklift Truck

Mast
The mast is a vertical assembly installed in the front of the forklift, responsible for lifting and lowering goods as well as supporting the fork. Therefore, this part is firmly built from materials with good bearing capacity. Thus, it is possible to ensure operational efficiency and ensure safety for users.

Carriage
The carriage supports the mast that is responsible for lifting the goods. This unit is made from thick steel to ensure that it can withstand large loads and contribute to the protection of goods during lifting.

Fork
The fork is the part of the electric forklift that directly acts on the pallets of goods during the operation of the truck. Almost L-like shape, attached to the lift by latches.

Counterweight
This is a very important part of an electric forklift. The counterweight has the function of balancing the forklift during handling goods.

Overhead Guard
The overhead guard on the electric forklift is made from sturdy metal which protects the safety of the driver, to help avoid falling objects from above as well as impacts from the outside.

Engine
Electric forklifts need an electric motor to operate. This engine is a closed motor system integrated inside the truck. Different truck models use different electric motors.

Control system
The forklift control system helps to connect the user with the truck's engine. This system operates through magnetic sensors and an internal control board system.

Controller board
Control boards contain electronic chips. This system of boards communicates with each other through chips to transmit signals from the driver to the forklift's components.

Wheels
Electric forklift wheels are made from high quality PU plastic or rubber. The wheel system on electric forklifts includes load wheels and steering wheels to help the truck move smoothly during operation.

Types of Electric Forklift Truck

Electric counterbalance forklifts

Electric counterbalance forklifts are similar to standard lp forklifts. Capacities May shift depending on the forklift size and the size of the battery, which serves as the counterbalance.

Stand up rider forklifts

Stand up rider forklifts are unique because operators stand during their use. Operators have their right side pointing toward the forks to easily check the front and the rear of their forklift.

Order pickers

Order pickers are specifically designed for use in warehouses and order fulfillment centers. Operators control order pickers from a platform that moves with the forks, lifting operators up to 32.5 feet in the air.

Reach trucks

Reach trucks are ideal fits for warehouses and distribution centers for putting away and retrieving full pallets. This specialized piece of equipment uses a folding pantograph on the mast to reach the fork into racking.

Electric turret trucks

Turret trucks are another electric forklift option for very narrow aisles. These forklifts can operate in aisles as narrow as 7-foot widths thanks to their unique mast and forklift carriage. The fork face can swing up to 90 degrees left and right on a chain turret.

Mechanical Principles of Electric Forklift Truck

Lifting of Goods

The operator starts the hydraulic pump, which pressurizes the hydraulic oil and delivers it to the hydraulic cylinder on the mast. The hydraulic oil pushes the piston upward, driving the mast to extend and retract, and the forks rise accordingly. When lowering, the pressure is released through the hydraulic valve, and the forks descend smoothly under the action of gravity. The entire process is precisely controlled by the hydraulic system to avoid cargo shaking.

Tilting of Goods

The bottom of the mast is equipped with a tilting hydraulic cylinder. The pressure of the hydraulic oil pushes the mast to tilt forward or backward. Forward tilting facilitates picking up and placing goods, while backward tilting prevents goods from slipping during transportation, especially enhancing safety when turning

Movement of Goods

The power system drives the transmission, which transmits power to the driving wheels. The operator controls the steering wheel to change the direction of the steering wheels, and the braking system ensures smooth stopping under load. For internal combustion forklifts, power is transmitted through the clutch and drive shaft; electric forklifts are directly driven by motors, with faster response.

Application of Electric Forklift Truck

Warehousing and Distribution Centers: Electric forklift trucks are extensively used in warehouses and distribution centers for loading and unloading goods, stacking pallets, and transporting materials throughout the facility. Their quiet operation and zero emissions make them well-suited for indoor environments.

Manufacturing Facilities: Electric forklift trucks are commonly employed in manufacturing plants and factories for handling raw materials, components, and finished products. They provide efficient and reliable material handling solutions while minimizing noise pollution and air pollution.

Retail and Wholesale Operations: Electric forklift trucks are utilized in retail and wholesale operations, such as supermarkets, big-box stores, and wholesale distribution centers, for stocking shelves, moving merchandise, and handling deliveries. Their maneuverability and compact size make them ideal for navigating crowded aisles and tight spaces.

Food and Beverage Industry: Electric forklift trucks are preferred in the food and beverage industry for their clean and hygienic operation. They are used in food processing plants, cold storage facilities, and distribution centers for handling perishable goods, palletized products, and packaging materials.

Cold Storage and Freezer Applications: Electric forklift trucks equipped with specialized components for cold storage environments are utilized in refrigerated warehouses, cold storage facilities, and freezer applications. They can withstand low temperatures and maintain optimal performance in sub-zero conditions without emitting harmful emissions.

Pharmaceutical and Healthcare Facilities: Electric forklift trucks are employed in pharmaceutical manufacturing facilities, hospitals, and healthcare facilities for transporting medical supplies, equipment, and pharmaceutical products. Their clean and quiet operation is critical for maintaining sterile environments and patient comfort.

Construction and Building Materials: Electric forklift trucks are used in construction sites and building material yards for handling construction materials, such as lumber, bricks, concrete blocks, and roofing materials. They provide efficient and environmentally friendly material handling solutions for construction projects.

Ports and Shipping Terminals: Electric forklift trucks are utilized in ports, shipping terminals, and freight yards for loading and unloading cargo containers, moving shipping pallets, and transporting goods between storage areas and cargo ships. Their versatility and maneuverability make them valuable assets in maritime logistics operations.

Electric Forklift Truck Customization

Load Capacity Options
Different load capacities available for warehouse, factory, and logistics applications.

Lifting Height Customization
Mast height and lifting range can be customized for different stacking requirements.

Battery & Power Options
Lead-acid and lithium battery configurations available based on working conditions.

Fork & Attachment Customization
Fork length, side shifter, clamps, and other attachments can be customized.

OEM Service
Logo, color, packaging, and product labels can be customized for different markets.

Packaging and Shipping

Packaging	Wooden Box Packing (as customized)
Transportation methods	Road transport, rail transport, sea transport

FAQ

Q: What to know about electric forklifts?

A: While gas-powered forklifts handle the outdoor, heavy-duty work, electric models shine indoors where ventilation may be limited. Their emissions-free operation helps maintain air quality, while their quieter performance reduces noise in enclosed spaces, enhancing safety.

Q: What precautions should be taken when using an electric forklift?

A: Keep your legs, arms, feet, hands and head inside the forklift while driving. Never stand under or pass beneath raised forks, whether loaded or empty. Never use the forklift for anything other than your specified job tasks.

Q: How long does an electric forklift battery last?

A: Forklift batteries don't last forever. A standard lead-acid forklift battery is good for about 1,500 charging cycles. For a single-shift operation, this works out to about a five-year lifespan (if the battery is properly maintained).

As one of the most professional electric forklift truck manufacturers and suppliers in China, we're featured by quality products and good service. Please rest assured to buy high-grade electric forklift truck at competitive price from our factory.
