This stand‑on driving all‑electric stacker is a professional electric stacking machine. It is widely applied in warehouses, factories and logistics centers for pallet stacking, loading and unloading work. It combines comfortable operation, strong power and comprehensive safety protections to boost your material‑handling efficiency.

Products Description

Stand‑on Operation Platform

Built‑in stand‑on platform allows operator to stand onboard during travel. Suitable for frequent long‑distance warehouse handling, greatly improve working efficiency compared with walk‑behind models.

Heavy‑duty Robust Mast

High‑strength welded mast structure ensures stable lifting under full load. Multiple lifting height options available to meet different warehouse stacking requirements.

Ergonomic Control Handle

Humanized integrated control handle with mechanical steering design. Easy to master, supports AC stepless speed adjustment for flexible driving inside narrow aisles.

Solid Pallet Forks

Thickened sturdy forks for heavy‑duty workload. Available in 550mm and 680mm width options, well‑fitted for standard pallets for stable cargo handling.

Products Specifications

Item	Specification
Load Capacity	1000kg/1500kg/2000kg
Lifting height	1600/2000/2500/3000/3500mm
Lowered mast height	2080/1680/1880/2080/2330mm
Load center	600mm
Fork width	550/680mm
Lowest fork height	90mm
Min ground clearance	30mm
Fork length	1000mm
Wheel size, Front wheel	Φ250*75
Wheel size, Rear wheel	Φ80*70
Lifting motor	2.2kw
Driving motor	1.5kw
Turning radius	1600mm
Aisle width, with 1000*1200 pallet	2455mm
Aisle width, with 800*1200 pallet	2430mm
Overall length	2100mm
Overall width	880mm
Battery	24V 120Ah (Optional 210Ah)
Lifting speed, Laden / Unladen	100m/s 200m/s
Drive speed, Laden / Unladen	4km/h 5km/h
Max. gradient, Laden / Unladen	3% / 5%

Customization Options

Multiple Custom Options Available

Our stand‑on all‑electric stacker supports multiple custom modifications to match your unique working scenarios.

Custom Color

Custom body color is available according to your requirement

Widened straddle Legs

Enhance overall lateral stability. Suitable for open‑bottom and footed pallets, compatible with non‑standard wide pallets, lowering tipping risks.

Safety Guard Arms

Can be equipped with guard arms to protect operators and avoid cargo tilting during lifting.

C‑shaped clamp arms

Replaces standard forks to grip cylindrical goods tightly without pallets. Suitable for handling paper rolls, plastic film rolls, fabric rolls and oil drums.
