This self propelled mobile scissor lift features an advanced proportional control system for precise and responsive movement, allowing operators to fine-tune speed for delicate positioning tasks. The powerful DC drive system delivers strong climbing ability on slopes and uneven terrain, while the compact frame ensures easy maneuvering in tight areas. Designed with efficiency and sustainability in mind, this lift offers reliable performance and long-lasting durability while remaining cost-effective, making it an ideal solution for industries seeking high productivity and minimal environmental impact.
Application
1.Warehouse material handling and logistics operations
2.High-altitude operations at airports, train stations, and transportation hubs
3.Equipment installation, commissioning, and maintenance
4.Industrial maintenance, repair, and servicing work
5.Maintenance of stadiums, shopping malls, and public facilities
Operate Video:
Feature
1.Extendable Work Platform:
With 0.6-meter detachable extension platform expands your workspace. Combined with a non-slip steel platform and removable guardrails, it ensures safe and flexible operation.
2.Aviation-Grade Durability:
Seamless welding of Q235 manganese steel rectangular tubing creates a robust and durable frame.
3.Superior Hydraulic System:
Bucher hydraulic pump station provides smooth, leak-free lifting performance and is equipped with explosion-proof valves for enhanced safety.
4.Reliable Power and Control:
Trojan's high-capacity battery ensures all-weather operation, while an intuitive single-person control panel enables efficient single-person operation.
5.Smooth and Quiet Mobility:
High-elasticity, silent wheels effectively absorb shocks and reduce noise, while a wide-angle steering system and hydraulic disc brakes provide superior maneuverability.
Product Specifications
|
Parameter |
GTJZ10 |
|
Max. working height |
12.00m |
|
Max. platform height |
10.00m |
|
Safe working load |
320kg |
|
Extended Platform Safe Working Load |
113kg |
|
Platform size (L × W × H) |
2.29×1.13×1.1m |
|
Overall dimensions (L×W×H; guardrail not folded) |
2.495×1.19×2.45m |
|
Overall dimensions (L×W×H; guardrail folded) |
2.495×1.19×1.92m |
|
Platform extension size |
0.9m |
|
Min. ground clearance |
0.1/0.02m |
|
Wheelbase |
1.89m |
|
Turning Radius (Inner Wheel/Outer Wheel) |
0/2.2m |
|
Lifting/driving motor |
24V/3.3kw |
|
Lifting speed |
3-5m/min |
|
Machine Travel Speed (Collapsed State) |
3.5km/h |
|
Machine Travel Speed (Lifting State) |
0.8km/h |
|
Battery |
4×12V/200ah |
Products Description
Our self-propelled mobile scissor lifts are packed in durable wooden packages, which are constructed from high-strength plywood and reinforced timber beams to withstand impacts, compression, and rough handling, ensuring maximum protection during international transport and handling.
Our Advantages
Simplified Operation
One-touch lifting and dual control from the platform or operating panel allow easy adjustments, ideal for tasks requiring frequent height changes.
Stable & Precise
Hydraulic transmission ensures smooth, controlled lifting, making it safe and reliable for high-standard indoor or residential applications.
Power Versatility
Supports AC, DC, diesel, or gasoline engines, providing flexible and reliable power for a variety of site conditions.
Smart Maintenance
Fault code display on the control panel streamlines troubleshooting, reducing downtime and simplifying upkeep for continuous operation.
