3.0 T Diesel Forklift
3-ton diesel forklift is a primary model for heavy-duty outdoor material handling. With a rated load capacity of 3,000 kg and a load center of 500 mm, it is suitable for use in factories, warehouses, logistics parks, docks, and building material markets, capable of performing cargo loading and unloading, stacking, and short-distance transport.
Product Highlights
1.Adopting a wide field of view gantry, the driver's field of view is wider.
2.The whole vehicle comes standard with LED headlights.
3.The engine has been upgraded to a China IV standard with VP pump engine,and can be optionally equipped with Euro III,Euro V,EPA,Dual fuel engine
4.Adopting a central integrated control box,water proof.
5.Steel structure overhead guard-solid, sturdy, and durable.
6.LCD instrument cluster for convenient, intuitive viewing.
7.Wide rubber tires paired with a comfortable seat.
|
TECHNICAL SPECIFICATIONS FOR DIESEL FORKLIFT |
|||
|
Performance |
Model |
|
CPC30/CPCD30 |
|
Rated Capacity |
3000 kg |
||
|
Load Center |
500 mm |
||
|
Power Type |
Diesel |
||
|
Max. Lifting Speed (No-Load / Full-Load) |
450/440 mm/s |
||
|
Max. Towing Capacity (Full-Load / No-Load) |
18/20 km/h |
||
|
Max. Driving Speed (Full-Load /No-Load) |
15.5/10.5 kN |
||
|
Grade ability (Full-Load /No-Load) |
15/20 % |
||
|
Lifting Height |
(H1) |
3000 mm |
|
|
Free Lift Height |
80 mm |
||
|
Mast Tilting Angle (Forward-Backward) |
6/12 (∘) |
||
|
Min. Turning Radius |
2530 mm |
||
|
Min.Right Angle Aisle Width |
2050 mm |
||
|
Min. Ground Clearance |
135 mm |
||
|
Dimensions |
Overall Length (Including Fork) |
(A) |
4170 mm |
|
Overall Length (Without Fork) |
2950 mm |
||
|
Overall Width |
(B) |
1230 mm |
|
|
Overall Height (Mast Lowered) |
(H) |
2110 mm |
|
|
Overall Height (Mast Extended) |
(H2) |
4270 mm |
|
|
Overall Height to Overhead |
(H3) |
2105 mm |
|
|
Front Overhang |
(A1) |
465 mm |
|
|
Wheelbase |
(A2) |
1760 mm |
|
|
Front Tread |
(B1) |
1000 mm |
|
|
Rear Tread |
(B2) |
970 mm |
|
|
Tire |
Front Wheel |
28*9-15 mm |
|
|
Rear Wheel |
6.50-10 mm |
||
|
Fork |
Fork Width |
(B3) |
122 mm |
|
Fork Thickness |
(H4) |
45 mm |
|
|
Backrest Height |
1225 mm |
||
|
Fork Length |
(A3) |
1220 mm |
|
|
Engine |
Engine Model |
XINCHAI C490BPG |
|
|
Rated Power |
40 Kw |
||
|
Rotate Speed at Rate Power |
2650 rpm |
||
|
Max. Torque |
162 Nm |
||
|
Rotation Speed at Max. Torque |
1800~1900 rpm |
||
|
Type of Power Shift |
Mechanical/Hydraulic |
||
|
Curb Weight |
4100 kg |
||
Optional engines available
