Our 5 ton counterbalance diesel forklift is a heavy-duty material handling machine built for intensive working conditions. Powered by XINCHAI A498BPG diesel engine, it delivers stable and strong power, ideal for outdoor yards, factories and warehouses.
The mast and fork adopt thick high-strength steel, supporting full 5000kg rated load safely. It can tilt forward and backward to stabilize pallets during lifting. With optimized chassis structure, it keeps good maneuverability even in limited working space.
We provide mechanical and hydraulic transmission options to meet different operation habits. The whole machine is easy to inspect and maintain, reducing downtime. Custom services including color and attachments are available.
Key Features
Reinforced Fork
Built with thick high‑strength steel forks and heavy‑duty carriage. Resists deformation under heavy loads to guarantee secure pallet handling.
Robust Welded Mast System
Heavy‑duty multi‑stage welded mast ensures smooth lifting and tilting. Stable performance for high‑level stacking and material storage tasks.
Heavy‑Duty Deep‑Tread Tires
Deep‑groove tires deliver excellent traction. Perfect for yards, construction sites and all kinds of uneven outdoor working surfaces.
Powerful Diesel Engine
Equipped with proven XINCHAI A498BPG diesel engine, it outputs stable and sufficient power for heavy‑load outdoor tasks.
Products Specifications
| Item | Parameter |
|---|---|
| Rated Capacity | 5000 kg |
| Load Center | 500 mm |
| Power Type | Diesel |
| Max. Lifting Speed (Full-Load) | 330 mm/s |
| Max. Driving Speed (Full-Load) | 22 km/h |
| Max. Towing Capacity (Full-Load) | 15.5 kN |
| Gradeability | 15%(Full-load)/20%(No-load) |
| Lifting Height (H1) | 3000 mm |
| Free Lift Height | 150 mm |
| Mast Tilting Angle | 6° forward /12° backward |
| Min. Turning Radius | 2850 mm |
| Min.Right Angle Aisle Width | 2350 mm |
| Min. Ground Clearance | 180 mm |
| Overall Length (Including Fork) | 4410 mm |
| Overall Length (Without Fork) | 3190 mm |
| Overall Width | 1380 mm |
| Overall Height (Mast Lowered) | 2210 mm |
| Max. Lifting Height (H2) | 4320 mm |
| Overall Height to Overhead Guard | 2200 mm |
| Front Overhang | 545 mm |
| Wheelbase | 1980 mm |
| Front Tread | 1080 mm |
| Rear Tread | 970 mm |
| Front Wheel | 300-15 |
| Rear Wheel | 700-12 |
| Fork Width | 150 mm |
| Fork Thickness | 50 mm |
| Backrest Height | 1275 mm |
| Fork Length | 1220 mm |
| Engine Model | XINCHAI A498BPG |
| Rated Power | 45kW/2300r.p.m |
| Max. Torque | 193Nm/1600-1800r.p.m |
| Number of Cylinders | 4 |
| Bore X Stroke | 98×105 mm |
| Displacement | 3.168 L |
| Type of Power Shift | Mechanical / Hydraulic |
| Shift (Forward/Reverse) | 1/1 |
| Fuel Tank Capacity | 70 L |
| Battery Capacity | 12V/80Ah |
| Curb Weight | 5500 kg |
Optional Configurations
Custom Optional Parts & Engines
A wide range of optional configurations and attachments are available to match diverse working demands.
You can choose different cabins, high‑visibility masts, various tires, LED headlights and premium seats.
Multiple well‑known brand engines including ISUZU, MITSUBISHI, YANMAR, KUBOTA, CUMMINS, KOHLER are optional.
EPA‑compliant engine is provided for special market requirements. OEM & ODM customization is supported.
