Our heavy duty diesel counterbalance forklift is built for 6 tons heavy load material handling. It adopts mature QUANCHAI 4J1 diesel engine, delivering stable power and strong torque for continuous outdoor heavy work.
The hydraulic lifting system and tiltable mast provide smooth lifting and safe cargo handling. Thickened high-strength forks and overhead guard greatly improve operation safety. With good gradeability and proper turning radius, the forklift can work efficiently in yards, ports, construction sites and heavy industry warehouses.
This diesel forklift is durable and easy to maintain. OEM & ODM services are available to meet your customized demands such as different lifting height, fork attachments and paint colors.
Key Features
Reinforced Fork
Built with thick high‑strength steel forks and heavy‑duty carriage. Resists deformation under heavy loads to guarantee secure pallet handling.
Robust Welded Mast System
Heavy‑duty multi‑stage welded mast ensures smooth lifting and tilting. Stable performance for high‑level stacking and material storage tasks.
Heavy‑Duty Deep‑Tread Tires
Deep‑groove tires deliver excellent traction. Perfect for yards, construction sites and all kinds of uneven outdoor working surfaces.
Powerful Diesel Engine
Equipped with proven QUANCHAI 4J1 diesel engine, it outputs stable and sufficient power for heavy‑load outdoor tasks.
Products Specifications
| Item | Specification |
|---|---|
| Model | CPCD60F |
| Rated Capacity | 6000 kg |
| Load Center | 600 mm |
| Power Type | Diesel |
| Max. Lifting Speed (No-Load / Full-Load) | 470 mm/s |
| Max. Driving Speed (Full-Load / No-Load) | 26 / 28 km/h |
| Max. Towing Capacity | 53 kN |
| Gradeability (Full-Load / No-Load) | 15% / 20% |
| Lifting Height | 3000 mm |
| Free Lift Height | 150 mm |
| Mast Tilting Angle (Forward-Backward) | 6° / 12° |
| Min. Turning Radius | 3430 mm |
| Min. Right Angle Aisle Width | 3090 mm |
| Min. Ground Clearance | 230 mm |
| Overall Length (Including Fork) | 4750 mm |
| Overall Width | 1995 mm |
| Overall Height (Mast Lowered) | 2500 mm |
| Overall Height (Mast Extended) | 4420 mm |
| Overall Height to Overhead Guard | 2420 mm |
| Front Overhang | 635 mm |
| Wheelbase | 2250 mm |
| Front Tread | 1470 mm |
| Rear Tread | 1700 mm |
| Front Wheel | 8.25-15-14 |
| Rear Wheel | 8.25-15-14 |
| Fork Width | 150 mm |
| Fork Thickness | 60 mm |
| Backrest Height | 1365 mm |
| Fork Length | 1220 mm |
| Engine Model | QUANCHAI 4J1 |
| Rated Power | 85 kW |
| Rotate Speed at Rate Power | 2200 rpm |
| Max. Torque | 500 N.m |
| Rotation Speed at Max. Torque | 1650 rpm |
| Type of Power Shift | Hydraulic Power |
| Curb Weight | 8640 kg |
Optional Configurations
Custom Optional Parts & Engines
A wide range of optional configurations and attachments are available to match diverse working demands.
You can choose different cabins, high‑visibility masts, various tires, LED headlights and premium seats.
Multiple well‑known brand engines including ISUZU, MITSUBISHI, YANMAR, KUBOTA, CUMMINS, KOHLER are optional.
EPA‑compliant engine is provided for special market requirements. OEM & ODM customization is supported.
