Features of Mobile Scissor Lift
1. Stable Hydraulic Lifting System
Fitted with a mature hydraulic system, the lift delivers ultra-smooth lifting and lowering movements. It maintains steady performance at any working height, enabling safe and efficient daily operation in all working conditions.
2. Self-Propelled Design & Robust Structural Build
Adopting heavy-duty reinforced steel scissor arms, the machine features solid load-bearing capacity and structural stability. The integrated self-propelled travelling system allows flexible movement between different work zones, greatly boosting working efficiency for both indoor and outdoor projects.
3. Full-Range Safety Protection
This lift comes with complete safety mechanisms as standard. It includes safety guardrails, emergency stop buttons, manual emergency lowering function, tilt angle protection and overload protection, effectively preventing operational risks and protecting operator safety at all times.
4. Flexible & Customizable Configuration
Multiple standard lifting heights and load capacity options are available to suit diverse application needs. We also support personalized customization on platform size, tire type, machine color and power configuration to match specific project and site requirements.
Working Principle of Self-Propelled Scissor Lift
Standard Version:Operators navigate this self-propelled scissor lift to the work zone using the on-platform controls. Once positioned, engage the brake to lock the unit securely. The hydraulic system powers the scissor arms, raising the work platform to your desired height. Thanks to its self-propelled build, the lift can move slowly and steadily while elevated within the approved height range. There is no need to repeatedly lower and reposition the machine, which simplifies jobsite operations significantly. Upon completing maintenance, installation, construction and other tasks, lower the platform gently via the hydraulic system. You may then drive the lift to another work location or return it to storage. This user-friendly working process improves overall efficiency for warehouses, construction projects and a wide range of field service work.
Brief Version:
1. Drive the scissor lift into place and secure it at the worksite.
2. Start the hydraulic system to raise the platform to your target working height.
3. Perform all tasks safely from the stable elevated platform.
4. Reposition flexibly: travel slowly with the platform lifted within the permitted height limit.
5. Fully lower the platform once work is done, then move the equipment or put it into storage.
Components of Self Propelled Mobile Scissor Lift
Working Platform
Serves as a stable elevated workspace for operators to stand and carry tools and materials, delivering a safe and flat working area for all height-based operations.
Platform Control System
Features intuitive onboard controls that allow operators to complete all core operations directly from the platform, including lifting, lowering, forward movement, steering and travelling, for convenient and efficient on-site control.
Scissor Arm Assembly
Built with heavy-duty reinforced steel arms, this core supporting structure bears the full platform load and guarantees steady, vertical lifting and lowering without shaking, ensuring outstanding structural stability during operation.
Hydraulic System
Composed of hydraulic cylinders, hydraulic pump, drive motor and oil tank, the whole hydraulic unit provides consistent, powerful and smooth lifting power, ensuring reliable and jitter-free height adjustment.
Chassis & Drive System
Integrates a sturdy chassis, drive motors, steering mechanism and durable travelling wheels. This integrated structure ensures flexible steering, stable travelling and excellent on-site mobility across different grounds.
Safety System
Comes with a complete set of safety configurations including safety guardrails, emergency stop function, manual emergency lowering device, tilt protection and overload protection. It effectively avoids common operational hazards and fully safeguards operator safety.
Products Specification
| Model | MPGTJZ0406 | MPGTJZ0608 | MPGTJZ0608 | MPGTJZ0810 | MPGTJZ1012 | MPGTJZ1214 | MPGTJZ1416 |
| Maximum working height | 5.8 m | 7.8 m | 7.8 m | 9.8 m | 11.8 m | 13.8 m | 15.8 m |
| Maximum platform height | 3.8 m | 5.8 m | 5.8 m | 7.8 m | 9.8 m | 11.8 m | 13.8 m |
| Overall length | 1.44 m | 1.82 m | 2.39 m | 2.39 m | 2.39 m | 2.39 m | 2.79 m |
| Overall width | 0.70 m | 0.78 m | 1.16 m | 1.16 m | 1.16 m | 1.16 m | 1.25 m |
| Overall height (unfolded fence) | 1.86 m | 2.02 m | 2.21 m | 2.34 m | 2.47 m | 2.60 m | 2.60 m |
| Overall height (folded fence) | 1.46 m | 1.62 m | 1.7 m | 1.82 m | 1.94 m | 2.06 m | 2.1 m |
| Work platform dimensions (length x width) | 1.3*0.68 m | 1.68*0.78 m | 2.27*1.13 m | 2.27*1.13 m | 2.27*1.13 m | 2.27*1.13 m | 2.63*1.13 m |
| Platform extension size | 0.55 m | 0.9 m | 0.9 m | 0.9 m | 0.9 m | 0.9 m | 0.9 m |
| Wheelbase | 1.02 m | 1.35 m | 1.86 m | 1.86 m | 1.86 m | 1.86 m | 2.23 m |
| Ground clearance | 106mm/29mm | 106mm/29mm | 106mm/29mm | 106mm/29mm | 106mm/29mm | 106mm/29mm | 106mm/29mm |
| RATED LOAD | 230 kg | 230 kg | 450 kg | 450 kg | 320 kg | 320 kg | 230 kg |
| Extended platform rated load | 113 kg | 113 kg | 113 kg | 113 kg | 113 kg | 113 kg | 113 kg |
| Machine travel speed (retracted state) | 3.5 km/h | 3.5 km/h | 3.5 km/h | 3.5 km/h | 3.5 km/h | 3.5 km/h | 3.5 km/h |
| Machine travel speed (lifting state) | 0.8 km/h | 0.8 km/h | 0.8 km/h | 0.8 km/h | 0.8 km/h | 0.8 km/h | 0.8 km/h |
| Rise/fall time | 3-5m/min | 3-5m/min | 4-6m/min | 4-6m/min | 4-6m/min | 4-6m/min | 4-6m/min |
| Gradeability | 25% | 25% | 25% | 25% | 25% | 25% | 25% |
| Maximum allowable angle for work (front and back) | 3° | 3° | 3° | 3° | 3° | 3° | 3° |
| Maximum allowable angle for work (lateral) | 1.5° | 1.5° | 1.5° | 1.5° | 1.5° | 1.5° | 1.5° |
| Drive | Front wheel drive | Front wheel drive | Front wheel drive | Front wheel drive | Front wheel drive | Front wheel drive | Front wheel drive |
| Tire | Seamless solid tire | Seamless solid tire | Seamless solid tire | Seamless solid tire | Seamless solid tire | Seamless solid tire | Seamless solid tire |
| Tire Size | φ230*80mm | φ305*100mm | φ381*127mm | φ381*127mm | φ381*127mm | φ381*127mm | φ381*127mm |
| Power source | 2*12V/85AH | 4*6V/200AH | 4*6V/200AH | 4*6V/200AH | 4*6V/200AH | 4*6V/200AH | 4*6V/240AH |
| Lifting motor | 1.2KW | 1.2KW | 24V/4.5KW | 24V/4.5KW | 24V/4.5KW | 24V/4.5KW | 24V/4.5KW |
| Drive motor | 2*0.5KW | 2*0.5KW | - | - | - | - | - |
| Charger | 24V/30A | 24V/30A | 24V/30A | 24V/30A | 24V/30A | 24V/30A | 24V/30A |
| Whole machine weight | 860 kg | 1200 kg | 2100 kg | 2250 kg | 2550 kg | 2950 kg | 3450 kg |
Self Propelled Mobile Scissor Lift Customization
Performance and Configuration Customization
We support flexible customisation of equipment configurations. We can tailor machine parameters to match different working scenarios, site environments and construction demands. Customers may adjust key specifications as required, such as platform size, rated load, maximum working height, lifting speed and overall dimensions.
Multiple power solutions are available: battery, AC electric and diesel drive, suitable for indoor warehouses, workshop servicing and outdoor construction worksites. We can also modify tire types, drive systems and platform designs according to ground conditions and onsite requirements, so the lift fits perfectly with your real-world operations.
Safety and Appearance Customization
We offer a full range of optional safety accessories and functional upgrades to make the lift safer and more user-friendly on site. Customers can equip the machine with extended platform decks, wear-resistant anti-slip tires, emergency lowering systems, overload protection and warning beacon lights. These practical configurations effectively reduce operating risks and greatly improve overall job efficiency.
We also support personalized appearance and detail customization. To match your brand image and project requirements, we can adjust the equipment color scheme, body logo markings and control panel layout according to your preferences. On top of that, we provide professional OEM and ODM solutions to satisfy diverse customized demands from different markets and customers worldwide.
fAQ
Frequently Asked Questions About Self Propelled Mobile Scissor Lift
Q:1.What is a self-propelled mobile scissor lift?
A:It is an aerial work platform combining lifting and travelling functions. Operators can carry out overhead work on the platform, and move the unit easily between different work zones to boost overall efficiency.
Q:2.Can the lift travel when the platform is raised?
A:Yes. It can move at low speed within the permitted height range. This avoids repeated lowering and repositioning, saving plenty of on-site working time.
Q:3.What power options are available?
A:We offer battery-powered, electric and diesel-driven versions to suit indoor warehouse use and outdoor construction sites.
Q:4.What safety features come as standard?
A:The machine is fitted with guardrails, emergency stop, emergency lowering device, overload protection and tilt protection systems.
Q:5.Where is this equipment commonly used?
A:It works well in warehouses, factories and construction sites, and fits all kinds of overhead tasks such as maintenance and installation.
Q:6.Is customisation available?
A:Yes. Working height, platform dimension, load capacity, power system, tire type, machine colour and logos can all be adjusted to match your project requirements.
