Our self‑propelled track scissor aerial work platform is specially engineered for complex and rough ground working conditions. Adopting robust steel crawler track chassis, this unit delivers outstanding off‑road performance on muddy, uneven construction sites. It features small turning radius, enabling easy access and flexible operation within narrow spaces.
Accurate and stable driving control brings convenient operation experience. Multiple built‑in safety mechanisms include tilt protection system, oil pipe anti‑explosion device, emergency lowering system and emergency stop button to safeguard operators during high‑altitude tasks. The extendable working platform expands operating space to support multi‑person simultaneous work.

Application

This crawler scissor aerial work platform is widely used for various tough‑site high‑altitude assignments.

Municipal engineering, landscaping and garden maintenance work
Power & communication equipment installation and inspection
Ports, stadiums and large‑venue decoration & maintenance
Outdoor construction sites with uneven, muddy ground

Key Features

Reliable Control System

Fitted with dedicated off‑road scissor level control system and proportional lifting control. Ensures safe logic and smooth, comfortable operation.

360° In‑place Steering

Supports 360‑degree stationary steering and unilateral steering, delivering great flexibility for tight and complex job‑sites.

Heavy‑duty Steel Track Chassis

Steel track structure brings strong ground adhesion and obstacle‑crossing performance. Protective track blocks for easy maintenance and long service life.

Strong Site Adaptability

Standard one‑key leveling support legs cooperate with in‑place steering function, easily coping with various harsh and complex ground conditions.

Product Specifications

Item	Parameter
Maximum working height	15.8 m
Maximum platform height	13.8 m
Overall length	2.9 m
Overall width	1.7 m
Overall height (unfolded fence)	2.74 m
Overall height (folded fence)	2.2 m
Work platform dimensions	2.63*1.13 m
Platform extension size	0.9 m
Rated load	227 kg
Extended platform rated load	110 kg
Driving speed (travel state)	3.5 km/h
Driving speed (lifting state)	0.0 km/h
Rise / fall time	3‑5 min
Gradeability	25%
Working allowable slope (front‑back)	3°
Working allowable slope (left‑right)	1.5°
Drive	Electric drive, steel track
Power source	8*6V/240AH
Lifting motor	48V/4.5KW
Walking motor	48V/4KW
Charger	48V /30A
Whole machine weight	3990 kg
