Our self‑propelled electric scissor lift features 5.8 m max platform height and 7.8 m maximum working height. Battery‑driven for low‑noise and zero‑emission performance, it is ideal for indoor workshops, shopping malls and building maintenance. Fitted with an extendable platform to enlarge the working area. Its compact body and zero inner turning radius enable flexible movement within confined spaces. Operators are allowed to drive while elevated to improve working efficiency.
Application
This self‑propelled electric scissor lift is designed for a wide range of indoor high‑altitude working applications.
- It serves factory workshops for daily maintenance, such as equipment inspection, ceiling assembly and lighting installation.
- It applies to malls and supermarkets for interior renovation, sign installation and decoration work.
- It meets the needs of exhibition events for booth erection and venue layout with the help of extendable platform.
- Equipped with non‑marking solid tires, it is available for hotels and office buildings to carry out refurbishment, high‑level cleaning and air‑conditioner maintenance.
Key Features
Products Specifications
| Item | Specification |
|---|---|
| Model | HC0608 |
| Maximum working height | 7.8 m |
| H Maximum platform height | 5.8 m |
| A Overall length | 1.82 m |
| B Overall width | 0.78 m |
| Overall height (unfolded fence) | 2.02 m |
| C Overall height (folded fence) | 1.62 m |
| Work platform dimensions (length × width) | 1.68*0.78 m |
| D Platform extension size | 0.9 m |
| Wheelbase | 1.35 m |
| Ground clearance | 106mm/29mm |
| RATED LOAD | 230 kg |
| Extended platform rated load | 113 kg |
| Machine travel speed (retracted state) | 3.5 km/h |
| Machine travel speed (lifting state) | 0.8 km/h |
| Rise/fall time | 3‑5m/min |
| Gradeability | 25% |
| Maximum allowable angle for work (front and back) | 3° |
| Maximum allowable angle for work (lateral) | 1.5° |
| Drive | Front‑wheel drive |
| Tire | Seamless solid tire |
| Tire Size | φ305*100mm |
| Power source | 4*6V/200AH |
| Lifting motor | 1.2 KW |
| Drive motor | 2*0.5 KW |
| Charger | 24V/30A |
| Whole machine weight | 1200 kg |
